HEAVY DUTY TRACTOR ripper with pipe layer

TRIDENT RIPPER WITH PIPE LAYER

WEICHAI LOVOL 8T steel tracked excavator with hydraulic quick hitch
Key features:
A/C cabin
Heavy duty chassis with steel track (rubber pads available)
High flow rate 159L/M
Yanmar direct injection engine, no computer, easy to service
High quality hydraulic pump
Pilot controls
Dozer blades
Touch screen control panel
Hydraulic outputs for multiple attachments
ENGINE/HYDRAULIC
Engine model YANMAR 4TNV98
Rate power 44.4kW/2100rpm
Displacement 3.32L
Maximum Torque/Speed 237Nm/1400rpm
4 cylinder
Flow rate 159L/min
Main Safety Valve Pressure 28MPa
Fuel Tank 160L
Hydraulic Tank 100L
Engine Oil 5-9.4L
OPERATING PARAMETERS
Vehicle working weight 7800kg
Travel speed 2.7-4.3km/h
Gradeability 35%
Swing speed 11.5rpm
Ground Pressure 35.1kPa
Bucket digging force 56kN
Arm digging force 38kN
Maximum traction force 61kN
Maximum digging radius 6335mm
Maximum digging depth 4050mm
Maximum vertical digging depth 3670mm
Maximum digging height 7150mm
Maximum dumping height 5030mm
Maximum Lifting height of dozer blade 375mm
Maximum Digging depth of dozer blade 295mm
EXCAVATOR DIMENSIONS
Bucket capacity 0.32m3
Shipping length 6100mm
Shipping ground length 3665mm
Boom height 2575mm
Shipping width 2275mm
Cab height 2650mm
Ground clearance of counter weight 820mm
Minimum ground clearance 378mm
Tail turning radius 1830mm
Length to center of rollers 2130mm
Track length 2770mm
Track gauge 1700mm
Track shoe width 450mm
Hood height 1750mm
Rotary platform width 2275mm
Boom length 3708mm
Arm length 1650mm
Track section number ?each side?38
Track roller number 5
Dozer blade height 425mm

TRIDENT 8T EXCAVATOR WITH HYDRAULIC QUICK HITCH

BACKHOE buckets kit (Ripper, Trench & Mud)

TRIDENT BACKHOE BUCKETS KIT (RIPPER, TRENCHING & MUD)

WEICHAI LOVOL 6T steel tracked excavator with hydraulic quick hitch
Key features:
A/C cabin
Heavy duty chassis with steel track (rubber pads available)
High flow rate 159L/M
Yanmar direct injection engine, no computer, easy to service
High quality hydraulic pump
Pilot controls
Dozer blades
Touch screen control panel
Hydraulic outputs for multiple attachments
ENGINE/HYDRAULIC
Engine model YANMAR 4TNV94L
Rate power 36.2kW/2100rpm
Displacement 3.054L
Maximum Torque/Speed 198Nm/1400rpm
4 cylinder
Flow rate 159L/min
Main Safety Valve Pressure 24.5MPa
Fuel Tank 120L
Hydraulic Tank 90L
Engine Oil 5.5-10.5L
OPERATING PARAMETERS
Vehicle working weight 5800kg
Travel speed 2.4-4.2km/h
Gradeability 35%
Swing speed 11rpm
Ground Pressure 32.33kPa
Bucket digging force 50kN
Arm digging force 31kN
Maximum traction force 49.4kN
Maximum digging radius 6065mm
Maximum digging depth 3660mm
Maximum vertical digging depth 2655mm
Maximum digging height 5405mm
Maximum dumping height 3770mm
Maximum Lifting height of dozer blade 400mm
Maximum Digging depth of dozer blade 560mm
EXCAVATOR DIMENSIONS
Bucket capacity 0.23m3
Shipping length 6090mm
Shipping ground length 3760mm
Boom height 2300mm
Shipping width 1950mm
Cab height 2660mm
Ground clearance of counter weight 700mm
Minimum ground clearance 330mm
Tail turning radius 1700mm
Wheel tread 2010mm
Track length 2550mm
Track gauge 1480mm
Track shoe width 400mm
Hood height 1635mm
Rotary platform width 1830mm
Boom length 3100mm
Arm length 1500mm
Track section number ?each side?40
Track roller number 5
Dozer blade height 360mm

TRIDENT 6T EXCAVATOR WITH HYDRAULIC QUICK HITCH A/C cabin Heavy duty chassis with steel track (rubber pads available) High flow rate 159L/M Yanmar direct injection engine

OVOL F4100 100HP 1450mm Narrow Vineyard & Orchard Tractor, Intercooled Turbo Diesel, Super steering front axle, Front & Rear PTO, 16F & 16R synchronizer shuttle shift (ABCDx1234xF&R), Electronic 4WD, PTO & Diff lock. 3 groups of hydraulic output, Bosch injection system

LOVOL 1450MM NARROW VINEYARD & ORCHARD TRACTOR, INTERCOOLED TURBO DIESEL, 4WD, FRONT & REAR PTO

TRIDENT 3.8T A/C cabin excavator plus 300mm, 450mm, 650mm and 1000mm Bucket, Thumb Grab, Ripper and Hydraulic Quick Hitch for $59,990 inc GST
Key features:
A/C cabin
Zero swing
Pilot controls
Swing boom
Bluetooth & Radio media system
Yanmar engine
Auto engine rev match
Touch screen control panel
Mechanical fuel pump (No engine ECU)
Hydraulic outputs for multiple attachements
ENGINE/HYDRAULIC
Engine model YANMAR 3TNV88F
Rate power 24.41HP/18.2kW/2200rpm
Displacement 1.642L
3 cylinder direct injection EPA Tier 4 Final/Europe Stage V Emission
Flow rate 96.8L/min
OPERATING PARAMETERS
Vehicle working weight 3800kg
Travel speed 2.4/4.4 km/h
Gradeability 30%
Swing speed 0-9rpm
Ground Pressure 32kPa
Bucket digging force 30.4kN
Arm digging force 18.2kN
Maximum digging radius 5345mm
Maximum digging depth 3075mm
Maximum vertical digging depth 2640mm
Maximum digging height 4910mm
Maximum digging distance 5500mm
Maximum dumping height 3545mm
Maximum Lifting height of dozer blade 375mm
Maximum Digging depth of dozer blade 370mm
EXCAVATOR DIMENSIONS
Bucket capacity 0.12 m3
Bucket width 650mm
Overall length 4880mm
Ground contact length(transportation) 3360mm
Overall height (to top of boom) 1880mm
Overall width 1740mm
Overall height (to top of cab) 2550mm
Counter weight ground clearance 595mm
Ground clearance 295mm
Tail Swing radius 860mm
Crawler wheel base 1670mm
Track length 2155mm
Track gauge 1440mm
Track width 1740mm
Shoe width 300mm
Bonnet height 1550mm
Revolving frame width 1550mm
Distance from swivel center to tail 860mm

TRIDENT 3.8T A/C CABIN EXCAVATOR, 4 X SIZES BUCKETS, THUMB GRAB, RIPPER AND HYDRAULIC QUICK HITCH A/C cabin, Yanmar engine, Zero swing, Pilot controls, Swing boom

TRIDENT 3.8T ROPS excavator plus 300mm, 450mm, 650mm and 1000mm Bucket, Thumb Grab, Ripper and Hydraulic Quick Hitch for $56,990 inc GST
Key features:
Zero swing
Pilot controls
Swing boom
Yanmar engine
Auto engine rev match
Touch screen control panel
Mechanical fuel pump (No engine ECU)
Hydraulic outputs for multiple attachements
ENGINE/HYDRAULIC
Engine model YANMAR 3TNV88F
Rate power 24.41HP/18.2kW/2200rpm
Displacement 1.642L
3 cylinder direct injection EPA Tier 4 Final/Europe Stage V Emission
Flow rate 96.8L/min
OPERATING PARAMETERS
Vehicle working weight 3800kg
Travel speed 2.4/4.4 km/h
Gradeability 30%
Swing speed 0-9rpm
Ground Pressure 32kPa
Bucket digging force 30.4kN
Arm digging force 18.2kN
Maximum digging radius 5345mm
Maximum digging depth 3075mm
Maximum vertical digging depth 2640mm
Maximum digging height 4910mm
Maximum digging distance 5500mm
Maximum dumping height 3545mm
Maximum Lifting height of dozer blade 375mm
Maximum Digging depth of dozer blade 370mm
EXCAVATOR DIMENSIONS
Bucket capacity 0.12 m3
Bucket width 650mm
Overall length 4880mm
Ground contact length(transportation) 3360mm
Overall height (to top of boom) 1880mm
Overall width 1740mm
Overall height (to top of cab) 2550mm
Counter weight ground clearance 595mm
Ground clearance 295mm
Tail Swing radius 860mm
Crawler wheel base 1670mm
Track length 2155mm
Track gauge 1440mm
Track width 1740mm
Shoe width 300mm
Bonnet height 1550mm
Revolving frame width 1550mm
Distance from swivel center to tail 860mm

TRIDENT 3.8T EXCAVATOR WITH 350MM, 500MM, 700MM AND 1000MM BUCKET, THUMB GRAB, RIPPER, QUICK HITCH

The TRIDENT 2.2T Excavator delivers powerful, versatile performance for any job site. Featuring zero swing, pilot controls, expandable tracks and a swing boom, it offers superior maneuverability. Equipped with a 3-cylinder water cooled Kubota engine for great power and fuel efficiency. With quick hitch, and multiple hydraulic outputs, it's ready for efficient operation. New features like side mirrors, a beacon light, and a protection grill provide added safety and visibility, ensuring you can work with confidence.
Combo deal includes:
- 450mm bucket
- 350mm trench bucket
- 1,200mm mud bucket
- 50mm ripper
- Post hole digger with 300mm auger
- 400mm stick rake
- Quick hitch
- Hydraulic thumb grab
- Hydraulic rock breaker
Key Features:
Zero swing
Pilot controls
Swing boom
Expandable track
3-cylinder water cooled Kubota D902 diesel engine
Hydraulic outputs for multiple attachments
Mechanical fuel pump (No engine ECU)
Engine & Hydraulic:
Engine model: Kubota D902-EF08
Rate power: 15.5kw / 20HP / 3600 rpm
Displacement: 898cc
Intake: Naturally Aspirated
Starting: Electric
Fuel type: Diesel
Cooling type: Water cooled
Operating Parameters:
Vehicle working weight: 2,200kg
Travel speed: 3.4 km/h
Swing speed: 10.5 rpm
Minimum swing radius: 1,580mm
Maximum digging depth: 2,270mm
Maximum dumping height: 2,550mm
Max. vertical digging depth: 1,910mm
Max. digging distance: 3,950mm
Maximum Lifting height of dozer blade: 280mm
Maximum Digging depth of dozer blade: 190mm
Dimensions:
Gross weight: 2,200kg
Overall width: 1,000mm - 1,300mm (adjustable)
Overall height: 2,450mm
Total length of track: 1,590mm
Total length with dozer: 1,720mm
Track height: 360mm
Platform ground clearance: 415mm
Platform back turning radius: 680mm

TRIDENT 2.2T EXCAVATOR COMBO DEAL (NEWLY UPGRADED)

Manufactured by Weichai Lovol Heavy Industry
LOVOL 70HP low base greenhouse model, 8 x 8 synchromesh gearbox with shuttle shift, 4WD,

LOVOL 70HP GREENHOUSE LOW CLEARANCE 4WD TRACTOR

Experience dependable power with our 12KW 15KVA Silent Diesel Generator featuring an Automatic Transfer Switch (ATS) for auto-start. This quiet, powerful generator is perfect for both agricultural and constructional use.
- High-performance diesel engine with air, oil, and fuel filters.
- Heavy-duty radiator and antivibration pads for stability.
- Robust steel frame with an 8-hour fuel tank.
- Thick, soundproofed, and insulated canopy for quiet operation.
- Doors with quality locks and hinges, offering easy 180° access for maintenance.
- Large-scale impedance muffler reduces noise further.
- Includes a maintenance-free battery and connecting cables.
- Smartgen control module with AMF for efficient power management; other systems optional.
- Comes with a battery charger and ATS port.
- Easy to move with four lifting eyes and forklift pockets.
- Ensures reliable, easy-to-manage power for continuity during outages.
- Functions better with double large mufflers (70dBA at 7m).
- Minimal vibration and smooth running.
- Large fuel tank ensures 8 hours' continuous running.
- Universal wheels facilitate easy movement.
SPECIFICATION:
Engine:
Engine model: 292FE
Starting system: Electric
Displacement: 997ml
Fuel consumption: 4.1L.h
Lube capacity: 2.75L
Fuel capacity: 26L
Alternator:
Voltage: 240V
Rated power: 11KW
Max power: 12KW
Frequency: 50Hz
Phase: single
Voltage distortion rate: 10%
Ambient temperature: 40
Power factor: cos = 0.8
Insulation level: F
Weight: 320KG
Dimension:
Length: 970mm
Width: 620mm
Height: 830mm

2024 TRIDENT 12KW 15KVA SILENT DIESEL GENERATOR WITH ATS (AUTO START)
